Koarse Bolt
Standaard: DIN 601
Type: Coarse Duur, Gedeilteleke Duur
Commoditeit: Koarse Bolt
Ouch Named: Coarse Dread Hex Bolt
Materiaal: koolstofsjtel
Eigensjapsklasse: 4.6, 4,8
Diameter: M5, M6, M8, M8, M10, M12, M16, M20, M20, M24, (M27), M30, (M33), M36, (M39), M42, (M45), M48, (M52)
Fins: Plain, Zwarte obstakel, Zink geplatteerd, Heit gegoejd, oosting, Dacromet, Phosffatie, Cadmium Elektroplate, Nickel geplaat
Hooftype: Hexagon Hoof
Drive-type: Externe ty
MOQ: 1000 kg
Lead Tied: 30 tot 60 daag
Product-introduksie
AYA-fasteners (Hebei) Co., Ltd. is ein vaan de mies ervare producente en leveranciers vaan grove bout in Sjina. Voel je vrij um hoogwaardige grove bout te kope die in China vaan oze febrik is gemaak. Veur prijsconsultatie, neem contact op mèt ons.
Es wereldwijde leverancier vaan aongepaste bevestigingsoplossinge, is ‘t deensproces vaan AYA ouch zoe dicht bij klante es de producte vaan AYA. Vaan ‘t besjrieve vaan behoefte tot ‘t volge vaanát--up dienste, AYA zal onmiddellek en gein poginge spare um klante te helpe vastlossingsprobleme op te losse die opkaome, um de zörg vaan klante te eliminere.
PRODUCT DESCRIEK
Produkt Naom | Koarse Bolt |
Ouch genaomp | Koarse Draad Hex Bolt |
Materiejaal | Koolstofsjtel |
Sjtandaard | DIN 601 |
Goede Klas | 4.6, 4.8 |
Dimeter | M5, M6, M8, M10, M12, M16, M20, M24, (M27), M30, (M33), M36, (M39),M42, (M45), M48, (M52) |
Eindsjtreep | Plain, Zwarte Verzet, Zink, Gebed Gegrild, oxidatie, Dacromet, Phosffat, Cadmium Elektroplate, Nickel |
Hooftype | Hexagon Hoof |
Drieft-type | Extern Hex |
Type | Koarse Duur, Gedeiltelek Thread |
DIENTSIES TABLE
| Schroef Behoerd | M5 | M6 | M8 | M10 | M12 | M16 | M20 | M24 | (M27) | |
| d | ||||||||||
| P | Sjmiete | 0.8 | 1 | 1.25 | 1.5 | 1.75 | 2 | 2.5 | 3 | 3 |
| b | L mie of geliek aon 125 | 16 | 18 | 22 | 26 | 30 | 38 | 46 | 54 | 60 |
| 125) Minder of geliek aon 200 | 22 | 24 | 28 | 32 | 36 | 44 | 52 | 60 | 66 | |
| L＞200 | 35 | 37 | 41 | 45 | 49 | 57 | 65 | 73 | 79 | |
| c | max | 0.5 | 0.5 | 0.6 | 0.6 | 0.6 | 0.8 | 0.8 | 0.8 | 0.8 |
| da | max | 6 | 7.2 | 10.2 | 12.2 | 14.7 | 18.7 | 24.4 | 28.4 | 32.4 |
| dw | min | 6.7 | 8.7 | 11.4 | 15.4 | 17.2 | 22 | 27.7 | 33.2 | 38 |
| ds | Nominale Grootte | 5 | 6 | 8 | 10 | 12 | 16 | 20 | 24 | 27 |
| min | 4.52 | 5.52 | 7.42 | 9.42 | 11.3 | 15.3 | 19.16 | 23.16 | 26.16 | |
| max | 5.48 | 6.48 | 8.58 | 10.58 | 12.7 | 16.7 | 20.84 | 24.84 | 27.84 | |
| e | min | 8.63 | 10.89 | 14.2 | 18.72 | 20.88 | 26.17 | 32.95 | 39.55 | 45.2 |
| k | Nominale Grootte | 3.5 | 4 | 5.3 | 6.4 | 7.5 | 10 | 12.5 | 15 | 17 |
| min | 3.12 | 3.62 | 4.92 | 5.95 | 7.05 | 9.25 | 11.6 | 14.1 | 16.1 | |
| max | 3.88 | 4.38 | 5.68 | 6.85 | 7.95 | 10.75 | 13.4 | 15.9 | 17.9 | |
| k1 | min | 2.2 | 2.5 | 3.45 | 4.2 | 4.95 | 6.5 | 8.1 | 9.9 | 11.3 |
| r | min | 0.2 | 0.25 | 0.4 | 0.4 | 0.6 | 0.6 | 0.8 | 0.8 | 1 |
| s | maxáx=nominale groete | 8 | 10 | 13 | 17 | 19 | 24 | 30 | 36 | 41 |
| min | 7.64 | 9.64 | 12.57 | 16.57 | 18.48 | 23.16 | 29.16 | 35 | 40 | |
| Schroef Behoerd | M30 | (M33) | M36 | (M39) | M42 | (M45) | M48 | (M52) | |
| d | |||||||||
| P | Sjmiete | 3.5 | 3.5 | 4 | 4 | 4.5 | 4.5 | 5 | 5 |
| b | L mie of geliek aon 125 | 66 | 72 | 78 | 84 | - | - | - | - |
| 125) Minder of geliek aon 200 | 72 | 78 | 84 | 90 | 96 | 102 | 108 | 116 | |
| L＞200 | 85 | 91 | 97 | 103 | 109 | 115 | 121 | 129 | |
| c | max | 0.8 | 0.8 | 0.8 | 1 | 1 | 1 | 1 | 1 |
| da | max | 35.4 | 38.4 | 42.4 | 45.4 | 48.6 | 52.6 | 56.6 | 62.6 |
| dw | min | 42.7 | 46.5 | 51.1 | 55.9 | 59.9 | 64.7 | 69.4 | 74.2 |
| ds | Nominale Grootte | 30 | 33 | 36 | 39 | 42 | 45 | 48 | 52 |
| min | 29.16 | 32 | 35 | 38 | 41 | 44 | 47 | 51 | |
| max | 30.84 | 34 | 37 | 40 | 43 | 46 | 49 | 53 | |
| e | min | 50.85 | 55.37 | 60.79 | 66.44 | 71.3 | 76.95 | 82.6 | 88.25 |
| k | Nominale Grootte | 18.7 | 21 | 22.5 | 25 | 26 | 28 | 30 | 33 |
| min | 17.65 | 19.95 | 21.45 | 23.95 | 24.95 | 26.95 | 28.95 | 31.75 | |
| max | 19.75 | 22.05 | 23.53 | 26.05 | 27.05 | 29.05 | 31.05 | 34.25 | |
| k1 | min | 12.4 | 14 | 15 | 16.8 | 17.5 | 18.9 | 20.2 | 22.2 |
| r | min | 1 | 1 | 1 | 1 | 1.2 | 1.2 | 1.6 | 1.6 |
| s | maxáx=nominale groete | 46 | 50 | 55 | 60 | 65 | 70 | 75 | 80 |
| min | 45 | 49 | 53.8 | 58.8 | 63.1 | 68.1 | 73.1 | 78.1 | |
PRODUCT DETAILEN
PRODUCT ADVANTAGE
ADVANTAAGE VAN Coarse Bolt
1. Coarse boute heet ‘n groetere weerstand veur ‘t striepe en kruuscros…oonder ‘t threde ten opziechte vaan de fijne boute.
2. ‘t Kin sneller samegevoeg weure es de fijne boute.
3. Het heet ‘n lang serviceleve door zien hoege- kwaliteit ruw maatsjappe.
4. Milieu duurzaamheid. ‘t Kin good werke in extreme umgeving.
5. AYA heet ein R&D-centrum in Europa gevestig veur nuie producte en betere technieke.
6. AYA heet de producte geleverd aon mie es 400 klante oet mie es 50 lande.
VROUTIGHEID VEURTIGING
PACKAGE & CONTAINER LEVE
UEGE SCENARIOS
WIEZOE KOES AYA?
AYA levert exclusieve deenste aon 1000+ leie vaan de ganse wereld eder jaor, mèt ‘n uniek kettingservice-oplossingssysteem, hoeft allein op de moes te klikke um exclusief bevestigingsoplossing te kriege en geniet vaan deur{{1}<}to{2}} deurdienste.
